Single head with versatile processing range

• Cutting to length and stripping from 0.22 – 35 mm² (AWG 24 – 2) cables.
• Processing of cable cross-sections up to 35 mm², multipole conductors up to Ø 16 mm (0.63 in.). Even short cables or ribbon cables up to 40 mm (1.6 in.) wide can be processed without any problems.
• Innovative sensor technology as set-up aid and process monitoring.

Dual head for even more productivity

• The dual-head version of the Komax Kappa 330 has a double-blade stripping unit.
• With the double-blade stripping unit, various special knives can be used simultaneously for cutting and stripping.
• Particularly challenging wires can be processed quickly and precisely using special blades.
• Together with further options, the dual-head Komax Kappa 330 offers three processing steps in one pass.

Optional separating unit

• Several (also twisted) inner conductors can be separated quickly and gently – without loss of quality.
• Using the patented Komax roller system, the wires are pressed apart in a particularly gentle way.
• The forward and reverse function of the rolls allow even short wires to be processed with ease.

Optional slitting unit

• programmable depth adjustment
• fully controllable via touch operation
• high benefit
